وصف المنتج

إسم المنتج: LBFQ Surface Paper Roll Vertical Slitter Rewinder Machine
رقم المنتج: LBFQ-2

Usage:

LBFQ paper slitting rewinding machine is a automatic high speed jumbo roll to narrow rolls slitting machine.LBFQ slitting machine adopts three servo motors control and automatic taper tension, central surface rewinding. Frequency converter control motors, running smoothly in acceleration. The unwinder adopts the automatic ultrasonsic correction. The winding adopts A. B air shaft, two magnetic powder control (or choose servo motor). LBFQ slitting machine adopts PLC autometer count, automatic alarm.

Specifications：

Model (Support for customization)	LBFQ-1100	LBFQ-1300
Max.Width of unwinding roll	1100 mm	1300 mm
Max. Diameter of unwinding roll	1400 mm	1400 mm
Max. Diameter of unwinding roll	800 mm	800 mm
Min.Width of slitting	5 mm	5 mm
Voltage	220/380V/other	220/380V/other
Power	25kw	25kw
Dimension(LWH)	3450x3100x1650 mm	3450x3300x1650 mm
Weight	4000kg	4500kg
Production Capacity	0-350 m/min	0-350 m/min

Applications:

This machine is mainly used for gift paper, wall paper, waterproof materials and other decorative materials of rewinding.

LBFQ Surface Paper Roll Vertical Slitter Rewinder Machine

Packaging

Unwinding unit and main machine part are packed separately. We use PP plastic wrapping the machine first. Then fix the machine into wooden pallet and pack them with wooden case.

Packaging

After-sales service

We guarantee the quality of the main parts within 12 months. If the main parts go wrong without artificial factors within one year, we will freely provide them or maintain them for you. After one year, if you need to change parts, we will kindly provide you with the best price or maintain it in your site.
